DIMENSIONS |
|
JLX-AT |
JLX-MT |
JX-MT |
|
|
|
|
|
|
|
|
|
Overall Length |
mm |
|
4.470 |
|
|
Overall Width |
mm |
|
1.810 |
|
|
Overall Height |
mm |
|
1.695 |
|
|
Wheelbase |
mm |
|
2.640 |
2.640 |
|
Front Tread |
mm |
|
1.540 |
|
|
Rear Tread |
mm |
|
1.570 |
|
|
Ground Clearance |
mm |
|
200 |
|
|
Minimum Turning Radius |
m |
|
5.5 |
|
|
|
|
|
|
WEIGHT |
|
|
|
|
|
|
|
|
|
|
|
Curb Weight |
kg |
1.520 |
1.505 |
1.475 |
|
Gross Vehicle Weight |
kg |
2.070 |
2.070 |
2.070 |
|
|
|
|
|
ENGINE |
|
|
|
|
|
|
|
|
|
|
|
Type |
|
J20A DOHC |
|
Number of Cylinders |
|
4 |
|
Number of Valves |
|
16 |
|
Piston Displacement |
cc |
1,995 |
|
Bore x Stroke |
mm |
84,0 x 90,0 |
|
Compression Ratio |
ps/rpm |
10,5 : 1 |
|
Max. Output |
nm/rpm |
140 / 6.000 |
|
Max. Torque |
|
183 / 4.000 |
|
Fuel Distribution |
|
Multi Point Injection |
|
|
|
|
|
TRANSMISSION |
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
Gear Ratio |
1st |
2,826 |
4,550 |
4,550 |
|
|
2nd |
1,493 |
2,357 |
2,357 |
|
|
3rd |
1,000 |
1,695 |
1,695 |
|
|
4th |
0,688 |
1,242 |
1,242 |
|
|
5th |
- |
1,000 |
1,000 |
|
|
Reverse |
2,703 |
4,436 |
4,436 |
|
Final Gear Ratio |
|
5,125 |
4,300 |
4,300 |
|
|
|
|
|
CHASSIS |
|
|
|
|
|
|
|
|
|
|
|
Steering |
|
Rack and Pinion |
|
Brakes |
Front |
Ventilated Disc |
|
|
Rear |
Leading and Trailing Drum |
|
Suspension |
Front |
MacPherson Strut |
|
|
Rear |
Multi Link |
|
Tyres |
|
225 / 65 R 17 |
225 / 70 R 16 |
|
|
|
|
|
CAPACITY |
|
|
|
|
|
|
|
|
|
|
|
Fuel Tank Cap. |
Litre |
66 |
|
Seating Cap. |
Persons |
5 |
|
|
|
|
|
|
|
|
|
